High initial permeability and high accuracy of transformer;
When the current has a DC component, it is not easy to saturate, ensuring the test accuracy of the transformer under certain DC conditions;
High and low temperature working performance is stable, and it can work for a long time at -55℃-130℃.
Material characteristics
納米晶 Nanocrystalline | 飽和磁感應強度Bs（T） Saturated magnetic induction | 1.2 | 非晶Amorphous | 飽和磁感應強度Bs（T） Saturated magnetic induction | 1.56 |
矯頑力Hc （A/m）Coercivity | <2 | 矯頑力Hc （A/m）Coercivity | <15 | ||
居里溫度Tc（℃） Curie temperature | 570 | 居里溫度Tc（℃） Curie temperature | 410 | ||
帶材厚度 thickness (mm) | 0.025～0.035 | 帶材厚度 thickness (mm) | 0.025～0.035 | ||
工作溫度 working temperature℃ | -55～130 | 工作溫度 working temperature℃ | -55～130 | ||
初始磁導率μi Initial permeability | 18×104 | 初始磁導率μi Initial permeability | 1000-3000 |
